Galvanometer Scanning Laser Welding Machine for Metals and Alloys

FOB Reference Price:Get Latest Price
$5,000.00 - $8,500.00 / Set | 1 Set/Sets (Min. Order)
Power(W):
300W
Model Number:
ZG-W300
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets) Less
Report Suspicious Activity
Overview
Quick Details
Usage:
welding
Max. Output Power:
200W
Condition:
New
Warranty:
1 year
After-sales Service Provided:
Online support, Field installation, commissioning and training, Video technical support, Engineers available to service machinery overseas
Place of Origin:
Hubei, China
Brand Name:
Chutian laser
Certification:
CE
Dimensions:
1100mm*600mm*1200mm
Single Pulse Energy:
40-80J
Pulse Width:
0.2-20ms
Focal Spot Diameter:
0.1-3.0mm
Wavelength:
1.06μm
Applicable Industries:
Manufacturing Plant
Laser Source Brand:
RAYCUS
Key Selling Points:
Sustainable
Keywords:
Galvanometer Laser Welding Machine
Laser type:
YAG
Cooling System:
Water Cooling
Continuous working time:
≥16h
Input voltage:
AC 220V 50Hz
Pulse Frequency:
0-50Hz
Power consumption:
3.5KW
Weight:
200kg
Customized:
Available
Supply Ability
Supply Ability:
100 Set/Sets per Month Galvanometer Laser Welding Machine
Packaging & Delivery
Packaging Details
Wooden package for international export standard
Galvanometer Scanning Laser Welding Machine for Metals and Alloys
Port
ShangHai
Picture Example:
package-img
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 To be negotiated

Galvanometer Scanning Laser Welding Machine for Metals and Alloys

Product Description

 Introduction:

Compared with the traditional method, the galvanometer laser welding machine replaces the two-dimensional worktable with high-speed moving scanning lens, and with the professional software of powerful graphic processing function, realizes the program-controlled instantaneous multi-point welding, which effectively improves the production efficiency and flexibility.

Parameters:

Product NameGalvanometer Scanning Laser Welding Machine for Metals and Alloys
Model No.ZG-sw30A
Laser SourceNd:YAG
Laser Wavelength1064nm
Power Consumption0-300w
Pulse Width≤20ms
Pulse Frequency≤50Hz
Beam Diameter0.2-2.0mm
Spot size adjustment range0.1-2.0mm
Maximum scanning speed<=7000mm/s
Resolution

0.005mm

                                                                                                                                                                                                                Features:

1.The welding speed is fast, which is more than 8 times faster than the traditional welding method.

2.For precision graphics, precision devices with many solder joints have advantages.

3. Configurable fiber-optic YAG laser and QCW fiber laser can realize one-to-two, one-to-three operation.

4. With industrial PC control, it can be perfectly combined with production lines and automatic lines.



Application

Applicable Industry:

This welder is widely used in aviation, aerospace, sports products, medical instrument, titanium alloy denture, instrument, electronics, machinery, automobile, etc.



Applicable Materials:

Materials that can be welded are extensive: cold work alloy steel, hot work alloy steel, nickel tool steel, steel alloy, high tenacity aluminum alloy, etc. Other metals like gold, silver, brass, aluminum-magnesium alloy, titanium, and platinum are also applicable.



Sample show:



More details, Please click here!!!

Hot Products

Company Information

As a leading laser system manufacturer, Wuhan Chutian Industrial Laser Equipment Co., Ltd. has been devoted to the design and production of industrial laser systems for over 30 years. Based on the domestic and international cooperation with laser, laser system and laser related components manufacturers worldwide.

From high power to small power Chutian Laser has been a major laser solution provider as Laser marking, Laser welding, Laser cutting as well as laser micro machining and 3D printing in China.

After 30 years of developing we've been able to continually upgrade with European and American laser technology. We sincerely welcome all the customers to visit our company!



Learn more about us, welcome to click https://chutianlaser.en.alibaba.com



Galvanometer Scanning Laser Welding Machine for Metals and Alloys

Packaging & Shipping

Packaging

Net Weight

 305KG 400KG
Package Volume 2.5CBM 3CBM
Package Weight 345KG

450KG

Delivery Time

The delivery lead time would be 7-15 day against down payment.

ShippingAs for the wholesalers/distributors,we could send the cargo by air, by sea or by railways via reliable forwarder



FAQ

Q1: Are you a factory or a trading company ?
A1: We are factory manufacturing packaging machines and we provide perfect OEM and after-sale service.

Q2: How was the machine guarantee?
A2: We offer you 12 months guarantee.

Q3: How can I use the machine, if I'm a new buyer?
A3: We will deliver English manual and video with the machine to you. If you still need our help, please contact us.

Q4: How do you control your quality?
A4: We'll test the machine before the shipment, and let it go through every corner to check the accuracy. Machines can not be dispatched until finished machine pass all essential complicated test after running at least two days without stopping to ensure quality.

Q5: How can I know your machine is designed for my product?
A5: You can send us samples of your product and we test it on machine.
